Welding Smoke Dust Collector Air Filter

FOB Reference Price:Get Latest Price
US $10-100 / Pieces | 20 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
Industrial dust collector
Efficiency:
99.99%
Minimum Particle Size:
0.3 micron
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Farrleey
Model Number:
PXX066325
Dimension(L*W*H):
350*240*660
Weight:
Depend
Certification:
ISO9001:2015
Warranty:
6 Months
After-sales Service Provided:
No overseas service provided
Filter media:
Toray spunbonded polyester
Top & bottom end cap:
Galvanized steel
Inner mesh:
Galvanized steel
Bolt hole:
10-16mm
Supply Ability
Supply Ability:
200 Piece/Pieces per Quarter
Packaging & Delivery
Packaging Details
Carton,packing size:365x365x690mm
Port
China seaport
Lead Time :
2-3 days
Product Description

Product Description



Advantage

1.Replace Donaldson air filter cartridge
2.Imported Toray spunbonded polyester



Filter material:

HL/PE  Typial spunbonded polyester

HL/LR  Water & oil resistant polyester

HL/AL  Anti-static coating polyester

HL/FM  PTFE membrane polyester

TE/FM  Donaldson Tetratex PTFE membrane polyester



Construction:
1) Unique plastic coating anti-rust caps and metal frame;
2) Wide pleat spacing,easy-cleaning design;
3) Unique plastic rotation,effectively separate the pleats,protect the filter media from abrasion by inner mesh;
4) Gasket,band;
5) Top open, bottom open/bottom close with deflating bolt hole.



Applications:

Mainly used in steel plate pre-processing for large-scale shipyards, container plants, smelters, foundries, large steel, locomotives, etc.



ModelFilter MediaSize(mm)Filtration Area(m2)
PXX066324HL/PE,LR ,FD,FM324×213×6609.4(HL)
PXX066350350x240×66012.5(HL)
PXX090324324×213/16×90014.6(HL)
PXX066324CE seriels324×213x66021(CE)
PXX066350350×240×66023(CE)
